Relative Humidity5~95% (Non-condensing)
| Processor |
| CPU |
Intel® Celeron J1900 2.0GHz 4 cores/4 threads 2MB L2 cache/Intel® Celeron J6412 2.0~2.6GHz 4 cores/4 threads 1.5MB L2 cache |
| Memory |
1 x SO-DIMM DDR4-2400MHz (max. 32GB) |
| Storage Medium |
1 x M.2 SSD 2242 SATA2.0/1 x M.2 SSD 2242 |
| BIOS |
AMI UEFI 64Mbit/AMI UEFI 256Mb |
| I/O Interface |
| LAN |
J1900:2 x RTL8111H GbE LAN1 x Intel GbE LAN/J6412:3 x Intel GbE LAN |
| USB |
2 x USB3.0 |
| COM |
1 x RS232 1 x RS485 |
| DO |
1 x Programmable LED |
| Display |
| DP |
J1900:Support up to 2560 x 1600 @60Hz/J6412:Support up to 4096 x 2160 @60Hz |
| HDMI |
J1900:Support up to 1920 x 1080/J6412:Support up to 3840 x 2160 @60Hz |
| Physical |
| Dimensions |
(L)138mm x (W)102mm x (H)48mm |
| Weight |
1.06Kg |
| Box Structure |
Aluminum-magnesium alloy BOX Fanless |
| Mounting |
| Mount |
Wall-mounted or DIN-Rail |
| Operating System |
| Microsoft Windows |
Windows 10 |
| Linux |
Ubuntu |
| Power |
| Input Voltage |
DC12/24V ±10% overcurrent overvoltage and polarity inverse protection. |
| Power Dissipation |
Max. 45W |
| Environment |
| Work temperature |
-20ºC ~ 60ºC (-4℉~140℉) with air flow (SSD) |
| Storage Temperature |
-40ºC ~ 80ºC (-40℉ ~ 176℉) with air flow (SSD) |
| Vibration |
5~500Hz 1.5Grms@with SSD Follow IEC60068-2-64 |
| Shock |
20G peak acceleration(11ms duration) with SSD Follow IEC60068-2-27 |
| EMC |
CE/FCC Class B |
| Other |
| WatchDog |
1~255 levels programmable |
| Expansion Slot |
| MiniPCIe |
1 x Full-size PCIe Mini slot with SIM card holder(with USB signal) |
Click below to download the datasheet
Datasheet
| Product |
Description |
| NP-6116-J6412 |
CPU: J6412, RAM: NULL, M.2: NULL, 1 x RS232, 1 x RS485, 3 x LAN, 3 x USB3.0, HDMI/DP display, DC12-24V DC IN |
| NP-6116-J1900 |
CPU: J1900, RAM: NULL, M.2 SATA: NULL, 1 x RS232, 1 x RS485, 3 x LAN, 1 x USB3.0, 1 x USB2.0, HDMI/DP display, DC12-24V DC IN |
| NP-6116-IO-N-J6412 |
CPU: J6412, Memory: NULL, M.2 SATA: NULL, 1 x RS232, 1 x RS485, 3 x LAN, 3 x USB3.1, 8 x DI, 8 x DO (NPN), HDMI/DP display, DC12-24V power input |
| NP-6116-IO-P-J6412 |
CPU: J6412, Memory: NULL, M.2 SATA: NULL, 1 x RS232, 1 x RS485, 3 x LAN, 1 x USB3.0, 2 x USB2.0, 8 x DI, 8 x DO (PNP), HDMI/DP display, DC12-24V power input |
| NP-6116-IO-N-J1900 |
CPU: J1900, Memory: NULL, M.2 SATA: NULL, 1 x RS232, 1 x RS485, 3 x LAN, 3 x USB3.1, 8 x DI, 8 x DO (NPN), HDMI/DP display, DC12-24V power input |
| NP-6116-IO-P-J1900 |
CPU: J1900, Memory: NULL, M.2 SATA: NULL, 1 x RS232, 1 x RS485, 3 x LAN, 1 x USB3.0, 2 x USB2.0, 8 x DI, 8 x DO (PNP), HDMI/DP display, DC12-24V power input |
| Parts |
Description |
| DDR3L Memory |
DDR3L-1333MHz: 4GB, 8GB |
| M.2 SSD |
64GB, 128GB, 256GB, 512GB |
| Wifi Set |
mini PCIE: Intel 7260 |
| 3G/4G Module |
mini PCIE, EC20, EG25, EC25 |
| Mount Option |
DIN-Rail |
